Jinko N Type Mono 580W Solar Panel

The Jinko N Type Mono 580W Solar Panel is a significant advancement in solar technology, providing exceptional efficiency, durability, and performance. Constructed with innovative materials and state-of-the-art technology, this mono-facial module is suitable for both residential and commercial solar applications. Let’s explore what sets this solar panel apart.

Jinko N Type Mono’s Key Features

High-Power Output

The panel delivers a maximum power of 580W with a module efficiency of up to 22.45%. Its N-type mono-crystalline cells and advanced technologies like Tunnel Oxide Passivating Contacts (TOPCon) ensure superior energy conversion and lower degradation rates.

Minimal Degradation for Long-Term Performance

• First-Year Degradation: Only 1%.
• Annual Degradation: A minimal 0.40%, ensuring over 87.4% of power output after 30 years.

This longevity is backed by a 12-year product warranty and a 30-year linear power warranty, ensuring confidence in the investment.

Anti-PID and HOT 3.0 Technology

Jinko's proprietary HOT 3.0 technology minimizes power loss due to potential-induced degradation (PID). Combined with its optimized cell production, this technology enhances the panel’s reliability even in harsh environments.

Enhanced Durability

• Certified for extreme conditions withstanding up to 5400 Pa of static front load and 2400 Pa of rear load.
• Resistant to salt mist and ammonia, making it suitable for coastal and agricultural installations.

Optimal Performance in Low-Light Conditions

The N-type module design excels under low-light conditions, delivering consistent performance even during early mornings or cloudy days.

Technical Specifications

• Dimensions: 2278 × 1134 × 30 mm
• Weight: 27.0 kg
• Cell Configuration: 144 (72×2) N-type mono-crystalline cells
• Temperature Range: -40°C to +70°C
• Efficiency: Up to 22.45% at STC (Standard Test Conditions)
• Module Tolerance: 0 ~ +3%

Electrical Ratings:

• Maximum Power Voltage (Vmp): 43.35V to 44.23V
• Maximum Power Current (Imp): 13.38A to 13.68A
• Open-Circuit Voltage (Voc): 52.31V to 53.11V
• Short-Circuit Current (Isc): 14.01A to 14.31A

Design and Build

The Jinko N Type Mono 580W Solar Panel is built with robust materials:

Front Glass

3.2mm tempered glass with anti-reflection coating for high transmission and durability.

Frame

Anodized aluminum alloy for corrosion resistance.

Junction Box

IP68-rated, ensuring maximum protection against dust and water ingress.

Connectors

JK03M/MC4 or other customizable options, with cables designed for flexibility and durability.

Eco-Friendly and Safe

Certified under multiple international standards, including ISO9001 (Quality), ISO14001 (Environmental), and ISO45001 (Occupational Health and Safety), the panel reflects JinkoSolar’s commitment to sustainability. Additional certifications for salt mist and ammonia resistance make it ideal for diverse environments.

Applications

Thanks to its robust design and high efficiency, this solar panel is ideal for:

Utility-Scale Projects

Reliable and efficient energy output for large solar farms.

Commercial Installations

Cost-effective for businesses looking to reduce energy costs.

Residential Use

A sustainable solution for powering homes.

Packaging and Transportation

To ensure safety during transit, the panels are packed efficiently:

Pallet Dimensions

2308 × 1120 × 1249 mm

Stacking Configuration

36 panels per pallet, 720 panels per 40' HQ container.

Why Choose Jinko N Type Mono 580W Solar Panel?

Investing in the Jinko N Type Mono 580W Solar Panel means opting for superior performance, reliability, and eco-friendliness. With its advanced technologies, high efficiency, and long warranty, it is a dependable choice for meeting energy needs sustainably.

Jinko N Type Mono 580W Solar Panel in Pakistan

The Jinko N Type Mono 580W Solar Panel is a premium choice for solar energy projects in Pakistan, known for its advanced technology and long-term reliability. Its price can vary based on factors such as dealer rates, market conditions, and installation requirements. However, ZAKSUN stands out by offering competitive and reasonable prices across Pakistan, ensuring accessibility for all customers. Additionally, ZAKSUN provides free delivery nationwide, making it a convenient and cost-effective option for anyone looking to invest in sustainable energy solutions.
